A How-To Guide on Pipe Cleaning Before CIPP Rehabilitation

Set yourself up for success by making sure to identify the pipe material of the damaged or problem pipe before you start the cleaning process

This content is sponsored by Nu Flow Technologies. Sponsored content is authorized by the client and does not necessarily reflect the views of COLE Publishing. View our privacy policy.
A How-To Guide on Pipe Cleaning Before CIPP Rehabilitation

Interested in Relining/Rehab?

Get Relining/Rehab articles, news and videos right in your inbox! Sign up now.

Relining/Rehab + Get Alerts

Whether you’re new to the CIPP lining industry or have been installing for decades, one step towards a successful CIPP lining rehabilitation job can be determined by the way in which damaged pipes are cleaned beforehand. The United States water infrastructure network is more than four times as long as the U.S. highway system and with that amount of pipe in the ground, there are bound to be a wide variety of pipe material types. Not all of these pipes clean the same way — that’s why understanding how to specifically clean for different pipe materials can set yourself up for a successful CIPP lining job.

Cast-Iron or Steel Pipe

Cast-iron pipes have the tendency to scale heavily and therefore take a longer time to clean due to removing the scale from the sides of the pipe and also removing the heavy debris knocked off from the bottom of the pipe. If there’s integrity to the pipe, the fastest way to clean is to use a jetter. Using a propulsion nozzle with a narrow angle can help remove the cast-iron debris on the bottom without damaging or descaling the sides of the pipe. Using your inspection camera while jetting can help you look for pipe integrity problems during the cleaning process. Once the debris is removed, using a mechanical spinning head can descale the pipe’s walls.

ABS, PVC and Copper

These types of pipe usually will need light cleaning or jetting. Clean with a jetter at low pressure, or just rinse the line out before CIPP lining. Grease will often stick to plastic pipe and may require a higher pressure of the jetter or mechanical cleaning. On copper pipe, certain brushes can clean the scale off.

Orangeburg

Orangeburg pipe or black pipe is pressed tarpaper pipe. It has the tendency to blister and will need a medium to heavy cleaning to knock down the blisters. While using a cutter go to the far end first and prep your way back to your access point. Pipe integrity is usually very poor in this type of pipe; therefore, holding the liner at a higher pressure will help remove some of the ovality in the original pipe.

Asbestos Concrete

This type of pipe material usually requires minimal prep work. It is a very thin pipe so be sure to not clean in one spot for too long with an aggressive cutter.

Clay

Clay pipe will usually have heavy root infiltration and a number of offsets. This pipe may need anywhere from light to heavy cleaning. Since the pipe is generally thick it can handle this kind of prep work before lining. Be careful not to dislodge broken pieces of clay during the prep because they are usually hard to remove from the pipe.

Whether you’re facing a cracked cast-iron sewer pipe, a misaligned clay pipe or PVC, knowing the different techniques for cleaning a wide verity of pipes is incredibly important before you start to rehabilitate the pipe system. Set yourself up for success by making sure to identify the pipe material of the damaged or problem pipe before you start the cleaning process.

For more information on pipe rehab and relining, call Nu Flow Technologies at 800/834-9597 or visit www.nuflowtechnologies.com.
